Thermoelectric cooling device
TECU-FF-100-24-4 (100 W)

Part #: FM202.068

Thermoelectric cooling devices (units) are designed to remove heat from distribution cabinets with radio-electronic equipment, control panels, etc. using convective and conductive heat transfer. They are used to prevent overheating and failure of electronic components and assemblies that are sensitive to high temperature, as well as for cooling various household appliances and industrial objects.

Overall Dimensions
Length	193 mm
Width	152 mm
Height	142 mm
Main Parameters
Weight	4,0 kg
Operating Voltage	24 V DC
Cooling Capacity	100 W
Noise	56 dB (A)
IP protection	54
Datasheet (download)
